Conductive Floor mat

This conductive floor mat is specifically designed for the electronics industry, where high reliability and quality are required. The mat offers excellent ESD properties, effective grounding, and very low charge accumulation during the “walking test” with ESD footwear. It is installed with floor adhesive and grounded via steel or copper strips placed under the mat to connect the seams. The mat is supplied in rolls of 2 × 20 m (40 m²) but can be cut to custom dimensions. It has a 2 mm thick, durable vinyl surface with a dissipative conductive backing, is elastic, recyclable, and complies with IEC 61340-5-1. Resistance to ground (Rgp) ranges from 10⁴ to 10⁶ ohms. The color is light gray.
